Indoor Model: CS-S24PKH, Outdoor Model: CU-S24PKH

Data sheet

Room Air Circulation

18.1 cubic-meter/min

EER (Energy Efficiency Ratio )

11.3 Btu/hW

Indoor Dimension (Width * Height * Depth)

290 mm * 1070 mm * 240 mm

Net Weight(Indoor)

12 Kg

Moisture Removal

3.5 L/h

Cooling Capacity (KW)

6.25 KW

Cooling Capacity (Btu/Hr)

21300 Btu/h

Maximum Pipe Length

20 m

Phase

1

Voltage

230 V

Running Current

8.6 A

Power Input

1880 W

Refrigerant Pipe Diameter(Liquid Side)

6.35 mm

Refrigerant Pipe Diameter(Gas Side)

15.88 mm

Chargeless Pipe Length

10 m

Maximum Elevation Lenght

15

Additional Refrigerant Gas

25 g/m

Power Supply

Indoor

Nanoe-G

Yes

Anti-Bacterial Filter

No

Odour-Removing Function

Yes

Removable & Washable Panel

Yes

Catching Air Purifying Filter

No

Solar Refreshing Deodorizing

No

Econavi

Yes

Temperature Wave

Yes

Auto Comfort

Yes

Inverter Control

Yes

Mild Dry Cooling

Yes

Quiet Mode

Yes

Powerful Mode

Yes

Soft Dry Operation Mode

Yes

Personal Airflow Creation

Yes

Airflow Direction Control

No

Manual Horizontal Airflow Direction Control

No

Manual Vertical Airflow Direction Control

No

Sleep Mode Auto Control

No

Automatic Operation Mode Cooling

Yes

24-Hour Dual ON OFF Real Setting Timer

Yes

24-Hour ON OFF Real Setting Timer

No

12-Hour ON OFF Setting Timer

No

LCD Wireless Remote Control

Yes

Wired Remote Control

No

Auto Restart

No

Random Auto Restart (32 Restart Patterns)

Yes

Blue Fin Condenser

Yes

Long Piping

20 m

Top-Panel Maintenance Access

Yes

Self-Diagnostic Function

Yes
