MSM-12CR

Data sheet

Cooling Capacity

12000 BTU/h

Room Air Circulation

530/460/320 cubic meter

Input Power

220-240/1/50 V/Hz

Power Consumption (Cooling)

1.35 KW

EER (Energy Efficiency Ratio )

2.61 KW

Indoor Dimension (Width * Height * Depth)

810 mm X 200 mm X 300 mm

Outdoor Dimension (Width * Height * Depth)

700 mm X 240 mm X 540 mm

Net Weight(Indoor)

8 Kg

Net Weight(Outdoor)

24 Kg

Connection Pipe Size (Small/Large)

6.35 mm / 12.7 mm

Max Height Difference

5 m

Permissible Range of Outdoor Temperature (Celsius)

18-43

Moisture Removal

1.2 L/h

Rated Current (Cooling)

6 A

Noise Level (Indoor)

H-39/M-34/L-27.5 db

Noise Level (Outdoor)

57 db

Max Connection Pipe Length

10 m
